15L Countertop Atmospheric Water Generator

WES15L Instruction Manual

I. INTRODUCTION
Thank you for purchasing the Atmospheric Water Generator. The Atmospheric Water Generator is a new, state-of-the-art water-generating machine, which uses some of the latest and most sophisticated technology
available in the industry today. We have designed your Atmospheric Water Generator with one objective in mind
i.e. to produce the most maximum amount of high quality drinking water while using only minimum amount of electricity. When hook up with city water or external water Tank supply, the machine can produce purified drinking water thus makes it a multi-functional machine.

II. SAFETY NOTES
1 The socket should be equipped with a reliable earthing protection and with a load capacity of 10 Amperes.
2 Do not remove the earthing terminal from the power cord.
3 Do not use an extension cord or an extension adapter.
4 Always keep the unit from poisonous gas and liquid.
5 Do not use a damaged electrical plug or power cable.
6 Unplug power cord before cleaning, installation, or maintenance.
7 Do not share the electrical socket with other high power consumption appliances.
8 Always use the correct replacement parts.
9 Do not unplug the power cord with wet hands.
10 Use the enclosed water pipe kits to connect with the city water inlet if this option is included on the machine. Do not use any old water pipelines to connect to the unit.
11 When moving the machine, please unplug the power cord and empty water of all tanks. Do not tilt the machine more than 20º during moving.
12 The machine is only intended for use by responsible persons and should not be used by young children without supervision.
13 Young children should be supervised around the machine.
14 Please allow the machine to stand upright for 30minutes before turning the machine on. This allows the refrigerant to settle after shipment.
15 Use the enclosed parts such as T-joint, plastic pipe and filters to connect with external water container.

Ⅲ. PRECAUTIONS
1 Do not place the unit too close to the wall. The best performance is obtained when the unit is placed at least 30 cm from the wall.
2 This unit is not for outdoor use.
3 Avoid prolonged exposure to direct sunlight.
4 Keep the unit working in an upright position.
5 The operating voltage must not drop below 10% of standard Power supply. When the unit operates below this level, the unit becomes noisy with the possibility of overheating. When this occurs, immediately switch the unit off until the voltage returns to normal.
6 Avoid prolonged direct eye exposure to the ultraviolet light as it may damage the eye.
7 This unit is not suitable for use at places with spray water, do not use spray water to clean the unit.
8 To prevent the machine from damage caused by freezing, please drain off the remaining water and stop operating the machine if the environment temperature during its working is below 0℃ (32oF).
9 If there is any damage to the power cables, the cables must be repaired or replaced
by an authorised person to avoid danger.
10 Please fix the unit with mounting bracket when using this unit on a shelf (as shown in the picture on above).
11 Do not place any object on top of the machine, there is no obstacle around the unit. Do not use machinery or any other way to accelerate the defrosting process, do not damage the refrigerating circuit. Good ventilation is required to ensure optimum performance.

Ⅳ. MAINTENANCE
1 Always keep the unit clean. Wipe the outer casing with a soft damp cloth to clean. Use water to clean and avoid using corrosive cleaning agent.
2 Do not use cleaning agent to clean water tanks.
3 The air filter should be cleaned regularly to ensure the normal air flow supply.
4 If you don’t use the machine for a long time, please unplug it and drain out all the water and clean the water tank.

Ⅴ. HOW IT WORKS?
It is important to be aware that your Atmospheric Water Generator is a humidity and temperature driven machine. This means the machine totally depends on the level of humidity in the air and the temperature to produce water. Ideally, the humidity level should be at least 80% or above to achieve the machine’s optimum performance. In places with a lower humidity level, the machine will still produce water but not as quickly, nor as much as in places with high level of humidity. In the house environment, a higher level of humidity tends to be around the kitchen area, near an open window or in more spacious rooms. This unit also performs well in an air-conditioned room, but it is recommended to open the window at night to allow the room to be ventilated.
Because your Atmospheric Water Generator works by converting the humidity in the air to water, this unit also acts as an effective dehumidifier. In areas with high humidity, it not only acts as a good water generator, but also as a dehumidifier.
To ensure high quality of drinking water, The Atmospheric Water Generator utilises multiple filtration technologies, including the most advanced and safe Reverse Osmosis (RO) technology, and the efficient UV technology for sterilisation of the water.
When the air is dry or or the temperature is too low (e.g., winter), the water production capacity will be slow. Connection to an external water container will make the machine serve as an excellent water purifier by utilising the RO filtration, UV sterilisation system and the special water re-circulation patent technology.

Ⅵ. FEATURES
1 Microcomputer
The unit is fitted with a microcomputer, which ensures proper working of internal parts.
2 Electronic Sensors
Various electronic sensors are attached to parts such as UV light and water tanks. These sensors ensure that all parts are working properly and warn you when a breakdown or performance irregularities occur in the machine.
3 Energy Saving Features
To conserve electricity, electronic sensors have been placed in the storage tank to automatically stop the machine from making more water when the tank is full.
4 Water Leakage Detector
In case of any unexpected situation of water leakage, the machine will stop working automatically and will be accompanied by a warning sound and a flashing screen.
5 Compressor variable frequency control system (only applicable to models with variable frequency control system)
The built-in high-performance variable frequency compressor adjusts according to the ambient temperature and humidity to save electricity consumption and reduce noise .
6 Condensing coils
Specially designed condensing coils are covered with a food grade coating to improve the efficiency of the water generation and to aid in the prevention of metal contamination from the water generation process.
7 Multi-Stage Filtration System
Our dedication to providing high-quality, great tasting water to our consumers is accomplished by our unique multi-stage filtration system. It can remove odor and reduce pollutants.
7.1 Anti-static / HEPA patented air-filter or electrostatic filter:
Before air becomes water drop through condensation, the air must go through the anti-static air filter to filter out dust particles and effectively block dust in the air from entering the machine.
7.2 LF2 active carbon filter
This device can remove organic compound, dust, and large particles in the air. It can also reduce the ammonia level in the water.
7.3 Bottom tank small filter:
Removes impurities in the water of the bottom tank, to protect the water booster pump for a longer operational life.
7.4 Multistage filtration system:
Our filter system removes impurities to produce great tasting clean water with a pH between 6.8 and 7.8.
7.4.1 Pre-Carbon Filter
Removes organic compounds, odours, free chlorine etc.
7.4.2 Post carbon filter
Further removes any colour, odours, residual chlorine etc., and improves the water quality.
7.4.3 Reverse Osmosis (RO) membrane
Mainly removes micro impurities, colloid, heavy metal, soluble solids, bacteria, and other harmful substances.
7.4.4 TCR carbon filter
The Total Contaminant Removal (TCR) post-filter contains activated carbon and is placed in a position where there is a longer contact time to ensure adsorption of any organic contaminant that might have escaped the reverse osmosis (RO) process.
The above filtration system for reference only, may change without prior notice.
8 Ultraviolet Sterilisation System
Our UV sterilisation system treats the water to ensure that bacteria and microorganisms are eliminated. The sterilisation process is controlled automatically by the microcomputer.
8.1. Top tank UV lamps remove bacterial growth in the top tank water.
8.2. Bottom tank UV lamps removes the bacteria in the bottom tank, reducing the bacterial level to a minimum in the bottom tank.
9 Water Re-circulation
Our patented exclusive technology ensures that stored water remains fresh and clean and avoids secondary contamination.
10 A Novel and Sharp Body design
The attractive modern design together with LCD display screen makes the machine easy to operate and more options to suit personal preference.
